MODEL
DC SIDE / INPUT PARAMETERS
Max DC power (W) 7500W
Max DC voltage (Vdc) 550
Min System start/Shut down voltage (Vdc) 75/100
MPPT voltage range(Vdc) 100-500
Max. input current (A) 22A
Max. input short circuit per MPPT 30A
Number of MPP trackers 1
Strings per MPP tracker 1
AC SIDE / OUTPUT PARAMETERS
Nominal output power (W) 5000
Maximum output power (W) 5500
Nominal output voltage/range (V) 208,220,230,240/180~270
AC grid frequency/range (Hz) 50Hz,60Hz(auto-selection) / 44Hz-55Hz; 54Hz-65Hz
Maximum output current (A) 23
AC connection (with PE) Single Phase
Current distortion (THDi) <2.5%
Power Factor ~1%(Adjustable from 0.8 leading to 0.8 lagging)
EFFICIENCY
Maximum conversion efficiency 97.5%
European efficiency 97.2%
MPPT efficiency 99.9%
SAFETY AND PROTECTION
DC reverse-polarity protection Yes
Anti-islanding / Overvoltage Protection Yes
Short circuit protection Yes
Leakage current protection Yes
Grid monitoring / Ground fault monitoring Yes
DC/AC side SPD (thermally protected) Yes
GENERAL PARAMETERS
Dimension (L/W/H)(mm) 370/318.5/105.5
Weight (kg) 7
Embedded DC Switch Optional
Night power consumption (W) <0.2
Isolation Transformerless
Protection Degree IP65 according to IEC60529
Operation temperature (ºC) -25 ~ +60
Cooling concept Smart Cooling
Operating Altitude (m) <2000m without power dera
Acoustic noise level (dB) <25
Display Graphic LCD
Communication Interface Standard WIFI; RS485 (optional)
